Compact automatic turnstile for access control

elegant and clean lines.
a complete solution ready for the future.

Genie is a complete and highly innovative turnstile.Thanks to its compact dimensions it can be installed in any location without taking up space, from the most modern halls to narrow environments such as corridors and landings, not obstructing the escape routes.

Its elegant and clean lines perfectly integrate with any type of environment. Genie, the innovative turnstile, is a state of the art and a complete solution ready for the future.

Main features:

  • Self supporting sturdy structure made of brushed tubular stainless steel
  • Thanks to an innovative patented mechanism the arm rotates around vertical axis
  • Automatic lowering of the arm in case of emergency, even in a power cut
  • Floor fastening system
  • High luminosity leds for pictograms and ambient lighting
  • Bidirectional
  • User passage mode in configurable in flap or traditional “tripod” turnstile mode
  • Intrusion detection
  • Disabled people access
  • Integrated diagnostics, easy monitoring
  • Multi standard RFID 13,56 MHz reader integrated (ISO 15693, 14443 A/B, Mifare, Desfire and NFC)

Technical characteristics:

  • Height: 100 cm at reading point
  • Recommented passage width: 590 mm
  • Weight: 14 kg
  • Flow capacity: 750 people/hv
  • Energy: low voltage for safety 24 V DC
  • Maximum consumption in rotation: 240 W
  • Maximum consumption in standby mode (waiting for user) 10 W
